Toro 74947 - Adjusting the Motion-Control Damper; Adjusting the Motion-Control Neutral-Lock Pivot

AdjustingtheMotion-Control
Damper
Youcanadjustthetopdampermountingbolttoobtaina
moredesiredmotion-controlleverresistance.SeeFigure83
formountingoptions.
Figure83
Rightmotion-controllevershown
1.Torquethelocknutto23N∙m(17ft-lb).Theboltmust
protrudepasttheendofthelocknutaftertorquing.
2.Mostresistance(rmestfeel)
3.Damper
4.Mediumresistance(mediumfeel)
5.Leastresistance(softestfeel)
AdjustingtheMotion-Control
Neutral-LockPivot
Youcanadjusttheangednuttoobtainthedesired
motion-controlleverresistancewhenyoumovethemto
theNEUTRAL-LOCKposition.SeeFigure84foradjustment
options.
1.Loosenthejamnut.
2.Tightenorloosentheangednuttothedesiredfeel.
Note:Formoreresistance,tightentheangednut.
Note:Forlessresistance,loosentheangednut
3.Tightenthejamnut.
Figure84
1.Flangednut2.Jamnut
59
