CheckingtheEngine-Oil
Level
Beforeyoustarttheengineandusethemachine,
checktheoillevelintheenginecrankcase;referto
CheckingtheEngine-OilLevel(page42).
BreakinginaNewMachine
Newenginestaketimetodevelopfullpower.Mower
decksanddrivesystemshavehigherfrictionwhen
theyarenew,placingadditionalloadontheengine.
Allow40to50hoursofbreak-intimefornew
machinestodevelopfullpowerandperformattheir
bestperformance.
Usingthe
Rollover-ProtectionSystem
(ROPS)
WARNING
Toavoidinjuryordeathfromrollover:keep
therollbarinthefullyraised,lockedposition
andusetheseatbelt.
Ensurethattheseatissecuredtothe
machine.
WARNING
Thereisnorolloverprotectionwhentheroll
barisinthedownposition.
•Lowertherollbaronlywhenabsolutely
necessary.
•Donotweartheseatbeltwhentherollbar
isinthedownposition.
•Driveslowlyandcarefully.
•Raisetherollbarassoonasclearance
permits.
•Checkcarefullyforoverheadclearances
(i.e.,branches,doorways,electricalwires)
beforedrivingunderanyobjects,anddo
notcontactthem.
Important:Ensurethattheseatissecuredto
themachine.
1.Tolowertherollbar,applyforwardpressureto
theupperpartoftherollbar.
2.Pullbothknobsoutandrotatethem90degrees
sotheyarenotengaged(Figure8).
3.Lowertherollbartothedownposition(Figure
8).
g008943
Figure8
1.ROPSknob
3.Rollbarintheupright
position
2.PulltheROPSknobout
androtateit90degrees.
4.Rollbarinthefolded
position
4.Toraisetherollbar,raisetherollbartothe
operatepositionandrotatetheknobssothat
theymovepartiallyintothegrooves(Figure8).
5.Raisetherollbartothefulluprightpositionwhile
pushingontheupperrollbarsothatthepins
snapintopositionwhentheholesalignwiththe
pins(Figure8).
6.Pushontherollbarandensurethatbothpins
areengaged.
Important:Alwaysusetheseatbeltwiththeroll
barintheraisedposition.
