Toro 75967 - Adjusting the Height of Cut; Adjusting the Anti-Scalp Rollers

AdjustingtheHeightofCut
UsingtheTransportLock
Thetransportlockhas2positions,andisusedwith
thedeck-liftpedal.ThereisaLOCKpositionanda
UNLOCKpositionforthetransportposition(Figure25).
g032377
Figure25
Transport-LockPositions
1.Transportlock3.UNLOCKposition—does
notlockthemowerdeck
intotransportposition
2.LOCKposition—mower
decklocksintotransport
position
AdjustingtheHeight-of-CutPin
Theheight-of-cutisadjustedfrom25to140mm(1
to5-1/2inches)in6mm(1/4inch)incrementsby
relocatingtheclevispinintodifferentholelocations.
1.Movethetransportlocktothelockposition.
2.Pushonthedeck-liftpedalwithyourfoot,and
raisethemowerdecktothetransportposition
(alsothe140mm(5-1/2inches)cuttingheight
position)asshowninFigure26.
3.Toadjust,rotatethepin90degreesandremove
thepinfromtheheight-of-cutbracket(Figure
26).
4.Selectaholeintheheight-of-cutbracket
correspondingtotheheight-of-cutdesired,and
insertthepin(Figure26).
5.Pushonthedecklift,pullbackonthetransport
lock,andslowlylowerthemowerdeck.
g027343
Figure26
1.Deck-liftpedal
3.Transportlock
2.Height-of-cutpin
AdjustingtheAnti-Scalp
Rollers
Wheneveryouchangetheheight-of-cut,adjustthe
heightoftheanti-scalprollers.
1.Disengagetheblade-controlswitch(PTO),move
themotion-controlleverstotheNEUTRAL-LOCK
position,andengagetheparkingbrake.
27
