AdjustingtheMyRide™

SuspensionSystem

TheMyRide™suspensionsystemadjuststoprovide

asmoothandcomfortableride.Youcanadjustthe

rear2-shockassembliestoquicklyandeasilychange

thesuspensionsystem.Positionthesuspension

systemwhereyouaremostcomfortable.

AdjustingtheRear-Shock

Assemblies

Theslotsfortherear-shockassemblieshave

detentpositionsforreference.Youcanpositionthe

rear-shockassembliesanywhereintheslot,notjust

inthedetentpositions.

Thefollowinggraphicshowsthepositionforasoftor

rmrideandthedifferentdetentpositions(Figure36).

g030065

Figure36

1.Firmestposition3.Detentsintheslots

2.Softestposition

Note:Ensurethattheleftandrightrear-shock

assembliesarealwaysadjustedtothesamepositions.

Adjusttherear-shockassemblies(Figure37).

g030024

g030019

Figure37
