Installation
15
m–3456
1
Figure 27
1. J–pin
12. If you wish to remove the pulley box, push the
latch release buttons on the front
Attach–A–Matic (Fig. 28) and raise the latch
levers to open the latches holding the pulley box.
Remove the pulley box.
m–3458
3
1
2
2
Figure 28
1. Front
Attach–A–Matic
button (one on each side)
2.
Front Attach–A–Matic
latches
3.
Pulley box
13. Start the tractor and raise the attachment lift.
Turn the steering wheel all the way to the left.
Then turn the ignition key to “STOP” to stop the
engine. Remove the ignition key.
14. Slide the mower out from the driver’s right–hand
side of the tractor. If the deck does not have
enough clearance from the front wheels once it is
almost out, turn the steering wheel all the way to
the right.
15. Replace the grille.
