InstallingtheBaggerTop
Partsneededforthisprocedure:
2
GrassBag
1Upperbaggertube
Procedure
1.Installthebaggertoptothebaggerframe.
2.Rotatethebaggertoptoalignthekeyholesinthe
baggertopbracketswiththekeysinthepostsonthe
baggerframe(Figure21).
3.Slidethebracketsoverthepostsandrotatethebagger
topdowntotheoperatingposition.
Note:Thebaggertopiseasiertoinstallif2people
worktogether.
G014888
1
2
3
4
5
6
Figure21
1.Baggertop4.Bracket,baggertop
2.Baggerframe
5.Key
3.Keyhole6.Post
4.Liftthebaggertopandinstallthebagsbyslidingthe
bagframehooksontotheretainingbrackets(Figure
22).
1
2
3
4
Figure22
1.Bag3.Retainingbracket
2.Baggerframe4.Bagframehook
5.Lowerthebaggertopontothebags(Figure23).
Figure23
6.Securethehoodwiththelatch(Figure23).
7.Installtheupperbaggertubebyinsertingthecurved
endintotheopeninginthebaggertop.
Note:Makesurethearedendwiththeretention
postispointingdownandfrowardinpreparationtobe
matedwiththeFinishingKit.
