Toro 79395 - Clearing Obstructions from the Bagger; Removing the Bagger; Using the Draw Bar

G005672
1
2
3
4
Figure31
1.Bag3.Retainingbracket
2.Baggerframe4.Bag-framehook
6.Lowerthebaggertopontothebags.
ClearingObstructionsfrom
theBagger
1.Parkthemachineonalevelsurfaceanddisengagethe
bladecontrolswitch.
2.Movethemotioncontrolleversoutwardtotheneutral
lockposition,stoptheengine,removethekey,setthe
parkingbrakeandwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
3.Checkthegrassbagsandemptythemiftheyarefull.
4.Separatethedischargetubeandchute.
5.Removethedischargetubeandchutefromthebagger
topandmowerdeck.Usingastickorsimilarobject,
carefullyremoveandcleartheobstructionfromthe
mower,dischargetube,chute,andthebaggertop.
6.Afteryouremovetheobstruction,installthecomplete
baggersystemandresumeoperation.
RemovingtheBagger
CAUTION
Failingtoremovethefrontbaggerweights
andoperatingthemachinewithoutthebagger
attachmentmaycauseanunstableconditionwhich
couldresultinalossofcontrol.
•Alwaysremovethefrontweightswhenremoving
thebaggerattachment.
•Neveroperatethemachinewithoutthebagger
attachmentandthefrontweightsstillinstalled.
ThebaggercanberemovedbyrepeatingtheSetupsections
fromallinstalledbaggerrelatedkitsinreverseorder.If
weightsareinstalled,alwaysremovethefrontbaggerweights
whenremovingthebaggerattachments.
Note:Itisonlynecessarytoremovethecutoffbafewhen
installingamulchingkit.
UsingtheDrawBar
Thebaggersupportbrackethasadrawbarfeaturethatcan
beusedfortowing.
•Readandunderstandalltheoperatinginstructionsofthe
machine.
•Whenturning,slowdownandobservetheclearance.
•Makewideturnsandkeeptowedequipmentclearofthe
towingvehicle.
•Themaximumdrawbarpullis80lb(36Kg).
•Excessivedrawbarpullmaycausehydrostatic
transmissionfailure.
g033033
1
Figure32
1.Baggersupportbracketwithdrawbar
16
