Toro 79395 - Installing the Chute

6
InstallingtheChute
Partsneededforthisprocedure:
1
Chute
1Knob
1
Carriagebolt(5/16x1-3/8inches)
1
Flangenut(5/16inch)
Procedure
1.Removetheplateassemblythatincludestheside
dischargechute(Figure24).
Note:Thebafewillcomeoffatthesametime.Save
thishardwareandplateassembly.
g017826
1
2
4
3
3
Figure24
1.Flangenuts
3.Carriagebolts
2.Plateassemblywith
dischargechute
2.Installtheexistingbafewiththeexistingboltsand
nutsafterremovingtheplateassembly(Figure25).
3.Installacarriageboltandangenutintothefronthole
showinFigure25.
g017823
1
2
3
5
4
Figure25
1.Newangenut(5/16inch)4.Existingbafe
2.Newcarriagebolt(5/16x
1-3/8inches)
5.Existingnuts
3.Existingbolts
4.Aligntheholeinthechuteandinstallitontothebolt.
Securethechutetothemowerdeckwiththeknoband
atwasher(5/16inch)(Figure26).
13
