g017824
1
2
3
4
Figure26
1.Knob
3.Chute
2.Flatwasher(5/16inch)
5.Hooktheexiblelatchonthechutetotheretaining
claspweldedonthemowerdecktotherearofthe
opening(Figure27).
g017825
1
2
3
Figure27
1.Chute3.Retainingclasp(weldedto
mowerdeck)
2.Flexiblelatch
6.Rotatethelatchuntilithooksintotheholeinthe
mowerdeckstiffener(Figure28).
g017842
1 2
Figure28
1.Latch2.Holeinthemowerdeck
stiffener
14
