ConnectingtheSafetyChainstothe
TowVehicle
1.Pullthesafetychainthroughtheslotsinthekeyholes,
sothatthelengthsoneachsideareequal.
2.Crossbothlengthsofchainunderthetowpole(under
thetongueforend-dumpmodels).Forside-dump
models,refertoFigure26.Forend-dumpmodels,
refertoFigure27.
Note:Crossingthechainsdecreasesthechancesof
thefrontofthemachinedroppingtothegroundifthe
hitchdoesnotholdtheconnection.
1
2
3
G021 177
Figure26
Side-DumpModels
1.Connectinglinks3.Chaincrossedundertow
pole
2.Keyholesinfrontpost
1
2
3
4
G019928
Figure27
End-DumpModels
1.Connectinglinks3.Chaincrossedunder
tongue
2.Keyholes
4.Chain
3.Connecteachlengthofchaintothesafetychain
mountingpointonthetowvehiclewiththeconnecting
links(Figure28).
Important:Ensurethatthechainhasenough
slackforturningaroundcornerswhentowingthe
machine.
Note:Forside-dumpmodels,stowtheexcesschain
insidethebottomofthefrontpostbypushingitinto
thekeyholesandlatchingtheappropriatelinksintothe
keyholeslots.
Note:Forend-dumpmodels,connecttheconnecting
linkstotheappropriatelinksinthesafetychain(Figure
28).Iftheexcesschainhangstoolowandtouchesthe
ground,connectitagaintotheconnectinglinktoraise
itawayfromtheground.
G020365
1
2
3
4
Figure28
1.Connectinglink3.Chainlink
2.Safetychainmounting
pointontowvehicle
4.Chain
20
