Toro DH 140 - Servicing the Grass Collector; Removing the Grass Collector; Installing the Grass Collector; Cleaning the Grass Collector and Tunnel

ServicingtheGrass
Collector
RemovingtheGrassCollector
1.Lockthelockingpinonthegrasscollector(Figure37).
1
G012470
2
Figure37
1.Topsupportbar
3.Lockingpin(unlocked
position)
2.Lockingpin
4.Lockingpin(locked
position)
2.Liftupthecollectorusingthetopsupportbar
(Figure37).
InstallingtheGrassCollector
1.Hangthetopsupportbarontothe2notchesinthe
supportbracketattherearofthemachine(Figure38).
1
2
G012467
Figure38
1.Topsupportbar2.Notchesincollector
supportbracket
Note:Ensurethatthegrasscollectorisproperly
seatedonthemower.Themowerwillnotfunction
unlessthegrasscollectorisproperlyattached.
2.Unlockthelockingpintoallowforemptyingthegrass
collector.
CleaningtheGrassCollector
andTunnel
1.Disengagetheblades(PTO).
2.Settheparkingbrake.
3.Stoptheengineandwaitforallmovingpartstostop.
4.Removetheignitionkey.
5.Removethegrasscollector;refertoRemovingthe
GrassCollector.
6.Cleanthecollectorbagwithpressurizedwater.
7.Wipetheareaaroundthefull-bagsensor.
8.Cleantheinsideofthedischargetunnelallthewayto
themower.
9.Installthegrasscollector;refertoInstallingtheGrass
Collector.
Note:Allowthebagtodrythoroughlybefore
installingit.
28
