Toro Dingo 323 Installation Instructions

ProcedureDescription
Qty.
Use
Parking-brakeleverassembly1
Clevispin(3/4inch)
1
5
Cotterpin(3/4inch)
1
Installtheparking-brakelever.
Wheel-hubassembly2
6
Hublocknut2
Installtherear-wheelhubs.
7
Nopartsrequired
–
Adjusttheparkingbrake.
Loader-valvelockassembly1
Self-tappingbolts(1/4x5/8inch)
2
Bolt(1/4x2inches)
1
8
Spacer
1
Installtheloader-valvelock.
9
CE-informationdecal
1
InstalltheCE-informationdecal.
1
PreparingtheMachine
NoPartsRequired
Procedure
1.Parkthemachineonalevelsurface.
2.Lowertheloaderarms.
3.Engagetheparkingbrake.
4.Shutofftheengineandremovethekey.
5.Raisethemachineoffthegroundandsupportit
usingjackstands.
Note:Usejackstandsratedforyourmachine.
RefertotheOperator’sManualforyourmachine
todeterminetheweight.
2
RemovingtheRear-Wheel
Hubs
NoPartsRequired
Procedure
1.Removetherearwheels.
2.Removeanddiscardthelocknutssecuringthe
rear-wheelhubs.
3.Usingahubpuller(K-LineSpecialServiceTools,
partnumberTOR4096),removetherear-wheel
hubs(Figure1).
g020924
Figure1
1.Hub2.Hubpuller
4.Savethekeyfromeachshaft.
