Toro Dingo 323 Installation Instructions

3
Assemblingthe
Parking-BrakeLocking
Mechanism
Partsneededforthisprocedure:
2Brakebar
2Brake-barbracket
2Flange-headbolt
2Brake-cablebracket
1Parking-brakecable
2Lockingcollarwithsetscrew
1Largespring
Procedure
1.Fastenthebrake-barbracketstothebrakebars
using2bolts(Figure2).
g020925
Figure2
1.Bolt3.Brakebar
2.Brake-barbracket
2.Arrangethebrakecablebracketsonaat
surface(Figure3).
g020926
Figure3
1.Brake-cablebracket2.Brakecable
3.Insertthecablethroughtherightbrake-cable
bracket(Figure3).
4.Slidethebrake-cablebarsthroughtheopenings
inthebrake-cablebrackets(Figure4).
g020927
Figure4
1.Brakecable3.Brake-cablebar
2.Brake-cablebracket
5.Setthecableintotherightbrake-barbracket,
andsecureitrmlyinplacewithalockingcollar
andsetscrewassembly(Figure5).
Note:Thecablemustbesecurelyheldinthe
bracketwithnomovement.
