Toro Dingo 323 Installation Instructions

g020928
Figure5
1.Lockingcollar
2.Setscrew
6.Positionthelargespringoverthecable(Figure
6).
g020929
Figure6
1.Largespring
7.Setthecableintotheleftbrake-barbracket,and
secureitwithalockingcollarandasetscrew
assembly(Figure7).
Note:Thecablemustbesecurelyheldinthe
bracketwithnomovement.
g020930
Figure7
1.Lockingcollar
2.Setscrewassembly
4
InstallingtheParking-Brake
LockingMechanism
Partsneededforthisprocedure:
1
Convolutedcabletube
4
Bolt(5/16x1inch)
4
Locknut(5/16inch)
Procedure
1.Slidetheconvolutedcabletubeoverthebrake
cable(Figure8).
g020931
Figure8
1.Parkingbrakecablewiththeconvolutedtube
2.Fromunderthemachine,routetheendofthe
cablethroughtheframeinthelower-leftcorner
oftheframe(Figure8).
Note:Ensurethatconvolutedcabletube
protrudesatleast10to15cm(4to6inches)
throughthehole.
3.Positionthebrakeassemblyunderthemachine
againstthebackoftheframewiththebrake
barsthroughtheholesinthesideoftheframe,
locatedinfrontofthewheelmotors(Figure9).
