WARNING
Thebladeissharp;contactingthebladecancause
seriouspersonalinjury.
Alwayswearglovesorwrapthesharpedgesofthe
bladewitharag.
1.Stopthemotorandwaitforallmovingpartstostop.
2.Removethekeyfromtheplugreceptacle.
3.Tipthemachineontoitsside.
4.Removethebladebyturningthebladeboltcounterclockwise
(Figure14).
Note:Grasptheendofthebladeusingaragora
thicklypaddedglove.
Figure14
1.Blade2.Bladeboltandwasher
5.Removethebladebolt,thewasher,andtheblade.
6.Installasharp,balancedblade,withthewasherandthe
bladeboltthatyoupreviouslyremoved.
7.Tightenthebladeboltto40to50ft-lb(54to68N-m).
8.Returnthemachinetotheoperatingposition.
ReplacingtheBatteryPack
Toreplacethebatterypack,contactanAuthorizedT oroService
Center.
DisposingoftheOldBatteryPack
Important:Donotplaceusedbatteriesinyour
householdtrash!
Important:Thissealedlead(acid)batterymustbe
collected,recycled,ordisposedofinanenvironmental
soundmanner.
Incinerating,landlling,ormixingsealedlead(acid)batterieswith
themunicipalsolidwastestreamisprohibitedbylawinsome
states.
Returnthisbatterytoanapprovedsealedlead(acid)battery
recycler.Thismaybewhereyoupurchasedthemachine.
Contactyourlocalwastemanagementofcialsforother
informationregardingtheenvironmentallysoundcollection,
recycling,anddisposalofthisbattery.
Service
Torohasdesignedthisproducttogiveyouyearsoftrouble-free
use.Shoulditneedservice,bringtheproducttoanAuthorized
ToroServiceDealerwhoisspeciallytrainedtorepairToro
productsandwillensurethatyourT orostaysallToro.
ProductInformation
Amodelandserialnumberdecalislocatedunderthereardoor
ofthemachine.Alwaysrefertospecicnumbersonthedecalin
correspondenceorwhenyouneedreplacementparts.
Storage
Storethemachineinacool,clean,anddryplacesuchasan
unheatedgarage.Donotstoreabattery-poweredmowerin
awarmbasement.Coverthemachinetokeepitcleanand
protected.
1.Cleanthemachinehousing.RefertoCleaningtheMachine
(page10).
2.Removeglassclippings,dirt,andgrimefromexternalparts
oftheshroudingandthetopofthemachinehousing.
3.Checktheconditionoftheblade.RefertoMaintainingthe
Blade(page10).
4.Tightenallloosenuts,bolts,andscrews.
Important:Thismachinehasabatterychargerthat
checksthechargestateofthebatteryandchargesthe
batteryonlywhennecessary.Unplugthechargerafter
24hoursofcharging,thoughyoumayleavethecharger
pluggedintothemachinelongerwithoutharmingthe
system.Duringthenon-mowingseason,youcanunplug
andstorethemachineforupto3monthsifthebattery
isfullychargedandthemachineisstoredinacool,dry
place.
11
