5.Insertthewireharnessconnectorsintothe
controlpanelhole.
6.Removethe4screwssecuringthecovertothe
leftsideofthemachine.Repeatfortheright
side.
g358653
Figure20
1.Hex-headscrew(4eachside)
7.Removethe3rearscrewsfromthecover.
g358652
Figure21
8.Removethe4topscrewsfromthecover.
g358654
Figure22
9.Carefullyliftthecoverandsetitdownnextto
themachine.
Note:Youdonotneedtodisconnectthewire
harnessfromthecontrols.
g358651
Figure23
10.Reversetheproceduretoinstallthecover.
Important:Aftermaintenance,ensurethatthere
arenoopencircuitsorloosewiring.
