Power Management Unit (PMU) Faults (continued)
Last 2 Digits of
Code
Fault Description
Corrective Action
2. Remove and charge the battery.
Install the battery.
3. If issues persist, replace the
battery or contact an Authorized
Service Dealer.
60-XXX-76
Battery 6 has indicated a relay failure.
1. Ensure that the battery is installed
properly.
2. Remove and charge the battery.
Install the battery.
3. If issues persist, replace the
battery or contact an Authorized
Service Dealer.
60-XXX-77
There is a positive metal-oxide-
semiconductor (MOS) failure in the
PMU.
Contact an Authorized Service Dealer.
60-XXX-79
A motor braking component is too hot.
1. Shut off the machine and allow it
to cool before starting it again.
2. Operate the machine in the
appropriate temperature range.
60-XXX-92 There is a PMU failure.
Ensure that the battery is fully seated
in the slot; if issues persist, contact an
Authorized Service Dealer.
60-XXX-93 There is a PMU failure.
Ensure that the battery is fully seated
in the slot; if issues persist, contact an
Authorized Service Dealer.
60-XXX-94
The PMU system is too hot.
1. Shut off the machine and allow it
to cool before starting it again.
2. Operate the machine in the
appropriate temperature range.
60-XXX-95 The PMU communication timed out.
Ensure that the battery is fully seated
in the slot; if issues persist, contact an
Authorized Service Dealer.
Primary Controller Faults
Code Fault Description Corrective Action
80-XXX-01 There is no controller area network
(CAN) signal for the left traction
controller.
Check for loose connections; if issues
persist, contact an Authorized Service
Dealer.
80-XXX-02 There is no CAN signal for the right
traction controller.
Check for loose connections; if issues
persist, contact an Authorized Service
Dealer.
80-XXX-07 A fault occurred in the left motion-
control sensor.
Check for loose connections; if issues
persist, contact an Authorized Service
Dealer.
Troubleshooting: Display Error and Fault Code
Troubleshooting
Page 7–6 3463-565 A
To Next Page
