Toro GrandStand 72523 User Manual

PerformingDaily
Maintenance
Beforestartingthemachineeachday,performthe
EachUse/DailyprocedureslistedinMaintenance
(page26).
BreakinginaNewMachine
Newenginestaketimetodevelopfullpower.Mower
decksanddrivesystemshavehigherfrictionwhen
new,placingadditionalloadontheengine.Allow
40to50hoursofbreak-intimefornewmachinesto
developfullpowerandbestperformance.
UsingtheSafety-Interlock
System
WARNING
Ifsafety-interlockswitchesaredisconnected
ordamaged,themachinecouldoperate
unexpectedly,causingpersonalinjury.
•Donottamperwiththeinterlockswitches.
•Checktheoperationoftheinterlock
switchesdaily,andreplaceanydamaged
switchesbeforeoperatingthemachine.
Understandingthe
Safety-InterlockSystem
Thesafety-interlocksystemisdesignedtoprevent
PTOfromengagingunlessyoudo1ofthefollowing:
•Moveeithermotion-controllevertothecenter,
unlockedposition.
•PresstheONpositiononthePTOswitch.
Thesafety-interlocksystemisdesignedtostop
theblades/attachmentifyoumoveorrelease
bothmotion-controlleversintotheNEUTRAL-LOCK
position.
Thehourmeterhassymbolstonotifytheuser
wheneachinterlockcomponentisinthecorrect
position.Whenthecomponentisinthecorrect
position,atrianglelightsupinthecorresponding
square(Figure8).
g031282
Figure8
1.Thetriangleslightupwhentheinterlockcomponentsare
inthecorrectposition.
TestingtheSafety-Interlock
System
ServiceInterval:Beforeeachuseordaily
Testthesafety-interlocksystembeforeyouusethe
machineeachtime.
Note:Ifthesafetysystemdoesnotoperateas
describedbelow,haveanAuthorizedServiceDealer
repairthesafetysystemimmediately.
1.Starttheengine;refertoStartingtheEngine
(page17).
2.Movethemotion-controlleverstothecenter,
unlockedposition.
Note:Theblades/attachmentshouldstopand
theengineshouldstoprunning.
3.Starttheengineanddisengagetheparking
brake.
4.Moveeithermotion-controllevertothecenter,
unlockedposition.
5.Continueholdingthemotion-controlleverin
thecenter,unlockedpositionandpresstheON
positiononthePTOswitch.
Note:Theclutchandblades/attachmentshould
engage.
6.Moveorreleasethemotion-controlleversinto
theNEUTRAL-LOCKposition.
Note:Theblades/attachmentshouldstopand
theengineshouldcontinuetorun.
7.PresstheOFFpositiononthePTOswitchand
moveeithermotion-controllevertothecenter,
unlockedposition.
8.Continueholdingthemotion-controlleverin
thecenter,unlockedpositionandpresstheON
positiononthePTOswitch.
13
