Greensmaster Flex 18/21 GroomerPage 8 – 3
General Information
Transport Mode
IMPORTANT: Before changing groomer position,
make certain that the reel drive lever is in the disen-
gaged position and that the cutting reel is not rotat-
ing.
IMPORTANT: When transporting the mower, make
sure the cutting unit is disengaged and the groom-
ing reel is raised to its transport position.
To place the grooming reel in the raised, transport posi-
tion, remove the lock screw and rotate the lift arm to
raise the grooming reel. Install the lock screw to retain
the grooming reel in the transport position (Fig. 1).
To place the grooming reel in the lowered, grooming
position, remove the lock screw and rotate the lift arm to
lower the grooming reel. Install the lock screw to retain
the grooming reel in the grooming position (Fig. 2).
1. Lift arm 2. Lock screw (transport)
Figure 1
1
2
1. Lift arm 2. Lock screw (grooming)
Figure 2
1
2
Groomer
