PreparingtheNewSeat
Model31654
Partsneededforthisprocedure:
1
Seatandsuspensionassembly
Procedure
1.Removethecoversandboltsthatsecurethe
seatbelttotheoldseatandremovetheseat
belt(Figure14).
2.Removethenutfromtherightarmrestand
removetherightarmrest(Figure14).
Retainthenutandarmrest.
g347421
Figure14
1.Removetherightarmrest
andnut.
4.Cover
2.Oldseat
5.Bolt
3.Seatbelt
6.Bushing
3.Assembletheseatbeltontothenewseatand
installthepreviouslyremovedarmrestusingthe
previouslyremovednut(Figure15).
Setthearmresttobethesameheightasthe
otherside.
4.Torquetheseatbeltboltsto70to75N∙m(52to
55ft-lb)andinstallthecovers(Figure15).
g347420
Figure15
1.Installthepreviously
removedarmrestusing
thepreviouslyremoved
nut.
4.Bolt
2.Seatbelt
5.Bushing
3.Cover
