ConnectingtheElectrical
Components
Partsneededforthisprocedure:
1
Standardfuse(10A)—Model31654
1
Minifuse(10A)—Models31657and31659
Model31654
1.LocatetheconnectorlabeledAIR-RIDEonthe
seatbehindtherubberboot.
Locatetheair-rideseatconnectoronthemain
wireharnessbreakoutandinstalltheconnector.
Note:Thebreakoutofthemainwireharness
islocatedbytheseat.
2.Connecttheseat-switchconnector.
3.Removethecoverfromthefuseblock(Figure
27).
g037069
Figure27
1.Fuse-blockcover
4.Insertthestandardfuse(10A)intothe5thfuse
positionfromtheleft(Figure28)ofthefuse
blockasfollows:
Note:Ensurethatthefuseisfullyseated.
g037201
Figure28
1.Standardfuse(10A)2.Fuse-blocksocket(5th
slotfromtheleft)
5.Installthecoverontothefuseblock(Figure27).
