5
Preparing
the
New
Seat
Models
31657
and
31659
Parts
needed
for
this
procedure:
1
Seat
and
suspension
assembly
Removing
the
Control
Arm
and
Seat
Belt
from
the
Seat
1.
Place
the
seat
and
control
arm
onto
a
bench.
2.
Remove
the
seat
cushion
to
gain
access
to
the
ange
nut
securing
the
control
arm
to
the
seat
(
Figure
16
).
g344858
Figure
16
1
1
10
12
Table of Contents
Table of Contents
1
No Parts Required
6
Seat and Suspension Assembly
10
Seat and Suspension Assembly
11
Locknut (8 MM)
18
Hex-Head Bolt (8 X 25 MM)
18
Standard Fuse (10A)-Model 31654
19
Mini Fuse (10 A)-Models 31657 and 31659
19
No Parts Required
21
