OperatingtheV-Plow

RefertoFigure5whilereadingthetablebelow .

Note:Totoggleoff,removeyourthumbfromthetoggleswitch.

JoystickAction

Toggle(LeftorRightside)On

ForwardLowerstheV-plow

BackRaisestheV-plow

LeftwithouttoggleActuatestherstsideoftheplow

Rightwithouttoggle

Actuatestherstsideoftheplow

LeftwithtoggleActuatesthesecondsideoftheplow

Rightwithtoggle

Actuatesthesecondsideoftheplow

Note:Thespecicactionoftheplowmayvarydependingonthebrandoftheplow .

OperatingtheSnowthrower

RefertoFigure5whilereadingthetablebelow .

Note:Totoggleoff,removeyourthumbfromthetoggleswitch.

JoystickActionFunction

ForwardLowersthesnowthrower

BackRaisesthesnowthrower

LeftRotatesthechutetotheleft

RightRotatesthechutetotheright

LefttoggleActuatesthedeectorintherstdirection

Righttoggle

Actuatethedeectorintheseconddirection

Note:Youcanswitchthedirectionofactuationcontrolledbythetoggleswitchbyswappingtheterminalsonthebackof

thepowerpointbox.
