Toro Groundsmaster 7210 Series - Transporting the Machine

Important:Alwayspushthemachinebyhand
andneveralongdistance.Nevertowthemachine,
becausedamagetothehydraulicsystemmay
occur.
Important:Thebypassvalvesmustbeopen
wheneveryoupushortowthemachine.Close
thevalvesonceyouhavepushedortowedthe
machinetothedesiredlocation.
1.Lifttheseat;refertoUnlatchingtheSeat(page
20)
2.Locatethebypassvalves(Figure61)androtate
eachbypassvalvecounterclockwise1turn.
Note:Thisallowshydraulicuidtobypassthe
pump,enablingthewheelstoturn.
Important:Donotrotatethebypassvalves
morethan1turn.Thispreventsvalvesfrom
comingoutofthebodyandcausinguidto
runout.
g004644
Figure61
1.Rightbypassvalve
2.Leftbypassvalve
3.Ensurethattheparkingbrakeisdisengagedand
pushthemachinetothedesiredlocation.
4.Closethevalvesbyrotatingeachvalve1
clockwiseturn(Figure61).
Note:Donotovertightenthevalves.
5.Torquethevalvestoapproximately8N∙m(71
in-lb).
Important:Ensurethatthebypassvalves
areclosedbeforeyoustarttheengine.
Runningtheenginewithopenbypassvalves
causesthetransmissiontooverheat.
TransportingtheMachine
Useaheavy-dutytrailerortrucktotransportthe
machine.Ensurethatthetrailerortruckhasall
thenecessarybrakes,lighting,andmarkingas
requiredbylaw.Pleasecarefullyreadallthesafety
instructions.Knowingthisinformationcouldhelpyou,
yourfamily,pets,orbystandersavoidinjury.
WARNING
Drivingonthestreetorroadwaywithout
turnsignals,lights,reectivemarkings,ora
slow-moving-vehicleemblemisdangerous
andcanleadtoaccidentscausingpersonal
injury.
Donotdrivethemachineonapublicstreet
orroadway.
1.Ifyouareusingatrailer,connectittothetowing
vehicle,andconnectthesafetychains.
2.Ifapplicable,connectthetrailerbrakes.
3.Loadthemachineontothetrailerortruck;refer
toLoadingtheMachine(page41).
4.Shutofftheengine,removethekey,engagethe
parkingbrake,andclosethefuelvalve.
5.Usethetie-downloopsonthemachineto
securelyfastenittothetrailerortruckwith
straps,chains,cable,orropes(Figure62).
g191318
Figure62
1.Tractionunittie-downloops
40
