4.Whilesupportingtheseat,removethe4locknuts(8mm)thatsecuretheseattotheseatplatform
(Figure10).
Donotremovethe4bolts(8x25mm)fromtheholesintheseatandseatplatform.
g343902
Figure10
5.Lowertheoperator’splatformasfollows:
A.Lowertheplatformcarefully(Figure11).
Note:Thegasliftcylinderhelpssupporttheplatform.
8
