Toro Power Max 724 User Manual

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Handlebolts2
Curvedwashers
2
1
Locknuts2
Installtheupperhandle.
Hairpincotter2
2
Flatwasher3
Installthetractioncontrollinkage.
Nut2
Carriagebolt
2
3
Flatwasher2
Installthechute.
Carriagebolts
2
4
Locknuts2
Installthechutecontrolrod.
5
Nopartsrequired
–
Checktheengineoillevel.
6
Nopartsrequired
–
Checkthetirepressure.
7
Nopartsrequired
–
Checktheskidsandscraper.
8
Nopartsrequired
–
Checktheoperationofthetractiondrive.
1
InstallingtheUpperHandle
Partsneededforthisprocedure:
2Handlebolts
2
Curvedwashers
2Locknuts
Procedure
1.Liftandrotatetheupperhandleandpositionitover
thelowerhandle(Figure3).
2.Install2handlebolts,2curvedwashers,and2locknuts
inthelowerhandleholes(Figure3).
g019003
Figure3
7

Toro Power Max 724 Specifications

General

Start Type	Electric Start
Auger Material	Steel
Forward Speeds	6
Reverse Speeds	2
Engine Type	4-Cycle OHV
Clearing Width	24 inches
Throw Distance	40 feet
Tire Size	15 in
Intake Height	20 inches
Stages	2
Headlight	Yes
Warranty	2-Year Full Warranty
