Toro ProCore 648 Installation Instructions

Operation
Compatible Machines
This trailer is designed to be congured for the
following ProCore Aerator machines without the need
for additional kits:
Machine Model
ProCore 648 Aerator
09200
ProCore 648s Aerator
09960
Contact your authorized T oro distributor for more
information.
Adjusting the T railer
T ongue
1. Align the trailer tongue with the tow-vehicle hitch.
Important: The trailer tongue must be
parallel to the ground when it is aligned with
the tow vehicle hitch.
2. Remove the clevis pins from the hitch adapter
and adjust the position up or down ( Figure 4 )
as necessary .
Note: The hitch adapter can be rotated for
further adjustment to the alignment.
g453999
Figure 4
1. Hitch adapter
3. Clevis pins
2. Hitch tube
3. Remove the clevis pins from the hitch tube and
adjust the length as necessary .
Important: Ensure that there is enough
clearance between the aerator handle and
the rear of the tow vehicle when towing.
Note: When storing the trailer , the hitch tube
can be pushed back into the trailer frame tube to
shorten the overall length.
5

Toro ProCore 648 Specifications

General

Aerating Width	48 inches
Fuel Capacity	6 gallons
Transmission	Hydrostatic
Aerating Depth	Up to 4 inches
Hole Spacing	3 inches
