Toro Recycler 20373 - Handle and Cutting Height Adjustment; Adjusting Handle Height; Adjusting Cutting Height

AdjustingtheHandleHeight
Youcanraiseorlowerthehandlein1of2positionsthatis
morecomfortableforyou(Figure15).
g195422
Figure15
1.Loosenbothhandleknobsuntilyoucanpushthe
squareedgesofthecarriageboltsoutofthesquare
holesinthehandlebrackets.
2.Pushtheknobsuntiltheyareloose.
3.Movethehandletotheupperorlowerheightposition.
4.Pulltheknobsuntilthesquareedgesofeachcarriage
bolttsintoitsrelatedsquarehole.
5.Tightenthehandleknobsastightasyoucan.
AdjustingtheCuttingHeight
WARNING
Iftheenginehasbeenrunning,themuferwillbe
hotandcanseverelyburnyou.
Keepawayfromthehotmufer.
Adjustthecuttingheightasdesired.Setallthecutting-height
leverstothesameheight.Toraiseandlowerthemachine,
refertoFigure16.
g195426
Figure16
1.Raisethemachine2.Lowerthemachine
g195425
Figure17
1.Frontcuttingheightlever
7.64mm(2-1/2inches)
2.Rearcuttingheightlever
8.73mm(2-7/8inches)
3.25mm(1inch)9.83mm(3-1/4inches)
4.35mm(1-3/8inches)10.92mm(3-5/8inches)
5.44mm(1-3/4inches)11.102mm(4inches)
6.54mm(2-1/8inches)
10
