Toro Recycler 20373 - Grass Bag Operation; Installing and Removing Grass Bag; Bag-on-Demand Lever

Note:Ifthebagdoesnotimmediatelydeate,the
bladeisstillrotating.Theblade-brakeclutchmaybe
deterioratingand,ifignored,couldresultinanunsafe
operatingcondition.Havethemachineinspectedand
servicedbyanAuthorizedServiceDealer.
5.Shutofftheengineandwaitforallmovingpartsto
stop.
NotUsingtheGrassBag
1.Movethemachineontoapavedsurfaceinanon-windy
area.
2.Setall4wheelstothe83mm(3-1/4inch)cutsetting.
3.Takeahalfsheetofnewspaperandcrumpleitintoa
ballsmallenoughtogounderthemachinehousing
(about76mmor3inchesindiameter).
4.Placethenewspaperballabout13cm(5inches)in
frontofthemachine.
5.Starttheengine.
6.Engagetheblade.
7.Releasetheblade-controlbar.
8.Immediatelypushthemachineoverthenewspaperball.
9.Shutofftheengineandwaitforallmovingpartsto
stop.
10.Gotothefrontofthemachineandcheckthe
newspaperball.
Note:Ifthenewspaperballdidnotgounderthe
machine,repeatsteps4through10.
11.Ifthenewspaperisunravelledorshredded,theblade
didnotstopproperly,whichcouldresultinanunsafe
operatingcondition.ContactanAuthorizedService
Dealer.
RecyclingtheClippings
Yourmachinecomesfromthefactoryreadytorecyclethe
grassandleafclippingsbackintothelawn.
Ifthegrassbagisonthemachineandthebag-on-demand
leverisinthebaggingposition,movethelevertotherecycling
position;refertoOperatingtheBag-on-DemandLever(page
13).Iftheside-dischargechuteisonthemachine,removeit;
refertoRemovingtheSide-DischargeChute(page14).
BaggingtheClippings
Usethegrassbagwhenyouwanttocollectgrassandleaf
clippingsfromthelawn.
Iftheside-dischargechuteisonthemachine,removeit;refer
toRemovingtheSide-DischargeChute(page14).Ifthe
bag-on-demandleverisintherecyclingposition,moveitto
thebaggingposition;refertoOperatingtheBag-on-Demand
Lever(page13).
InstallingtheGrassBag
1.Raiseandholdupthereardoor(Figure25).
g033379
Figure25
1.Reardoor
3.Grassbagpin(2)
2.Notches
2.Installthegrassbag,ensuringthatthepinsonthebag
restinthenotchesinthehandlebrackets(Figure25).
3.Lowerthereardoor.
RemovingtheGrassBag
Toremovethebag,reversethestepsabove.
OperatingtheBag-on-Demand
Lever
Thebag-on-demandfeatureallowsyoutoeithercollector
recyclegrassandleafclippingswhilethegrassbagisattached
tothemachine.
•Tobagthegrassandleafclippings,pressthebutton
onthebag-on-demandleverandmovetheleverforward
untilthebuttonontheleverpopsup(Figure26).
g195424
Figure26
1.Bag-on-demandlever(in
therecyclingposition)
2.Bag-on-demandlever(in
thebaggingposition)
•Torecycleorside-dischargethegrassandleaf
clippings,pressthebuttonontheleverandmovethe
leverrearwarduntilthebuttonontheleverpopsup.
Important:Forproperoperation,removeanygrass
clippingsanddebrisfromthebag-on-demanddoor
13
