Toro Recycler 20373 - Setup Procedures; Assembling and Unfolding the Handle

Setup
Important:Removeanddiscardtheprotectiveplastic
sheetthatcoverstheengineandanyotherplasticor
wrappingonthemachine.
1
AssemblingandUnfoldingthe
Handle
NoPartsRequired
Procedure
1.Removeandsavethe2handleknobsand2carriage
boltsfromthehandlebrackets(Figure4).
g195430
Figure4
1.Handleknob(2)2.Carriagebolt(2)
2.Installthehandleendsontothemowerhousingsothat
thepinattachedtoeachhandlebracketisinthelower
holeofitsrelatedhandleend(Figure5).
g032866
Figure5
1.Pin2.Handleend
Note:Thepinsdonotshowthroughtheholesinthe
handleendswhenthehandleisinthefoldedposition.
3.Unfoldthehandletotheoperatingpositionbyrotating
itrearward(Figure6).
g195431
Figure6
1.Operatingposition
2.Foldedposition
4.Insertthecarriagebolt(withtheboltheadtoward
theinside)throughtheupperorlowersquareholein
handlebracketandtheupperholeinthehandleend
(Figure7).
g032869
Figure7
1.Handleknob
2.Carriagebolt
5.Looselyinstallthehandleknobsontothecarriagebolts.
6.Refertosteps3through5ofAdjustingtheHandle
Height(page10).
