Toro Recycler 20373 - Assembling the Grass Bag; Grass Bag Assembly

3
AssemblingtheGrassBag
NoPartsRequired
Procedure
1.SlipthegrassbagovertheframeasshowninFigure9.
g027257
1
2
3
g027257
Figure9
1.Handle
3.Grassbag
2.Frame
Note:Donotslipthebagoverthehandle(Figure9).
2.Hookthebottomchannelofthebagontothebottom
oftheframe(Figure10).
g027258
g027258
Figure10
3.Hookthetopandsidechannelsofthebagontothetop
andsidesoftheframe,respectively(Figure10).
7
