g195429
Figure29
1.Washoutport
6.Turnthewateron.
7.Starttheengineandrunituntiltherearenomore
clippingsthatcomeoutfromunderthemachine.
8.Shutofftheengine.
9.Shutoffthewateranddisconnectthegardenhose
fromthemachine.
10.Starttheengineandrunitforafewminutestodrythe
undersideofthemachinetopreventitfromrusting.
11.Allowtheenginetocoolbeforestoringthemachine
inanenclosedarea.
FoldingtheHandle
WARNING
Foldingorunfoldingthehandleimproperlycan
damagethecables,causinganunsafeoperating
condition.
•Donotdamagethecableswhenfoldingor
unfoldingthehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Removeandsavethe2handleknobsand2carriage
boltsfromthehandlebrackets(Figure30).
Important:Routethecablestotheoutsideofthe
handleknobsasyoufoldthehandle.
g032869
Figure30
1.Handleknob(2)2.Carriagebolt(2)
2.Foldthehandlebyrotatingitforward(Figure31).
g195431
Figure31
1.Operatingposition
2.Foldedposition
3.Looselyinstallthehandleknobsandcarriageboltson
thehandlebrackets.
4.Tounfoldthehandle,refertoAdjustingtheHandle
Height(page10).
Maintenance
ReplacementpartsareavailablefromanAuthorizedService
Dealeroratwww.torodealer.com(UScustomersonly).
EnginepartsareavailableonlyfromanAuthorizedService
Dealer.
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
