Toro SGR-13 Operator's Manual

ProductOverview
g024550
Figure3
1.Throttlelever
8.Cuttingwheel
2.Hourmeter9.Beltcover
3.Cycloneairlter
10.Lifthandle
4.Choke
11.Fuelcap
5.Fuelvalve12.Parkingbrake
6.Sedimentcup13.Safetybail
7.Starter
14.Handle
Controls
Becomefamiliarwithallthecontrols(Figure3and
Figure4)beforeyoustarttheengineandoperatethe
machine.
SafetyBail
Thesafetybailcontrolstheengine.Holdthesafety
bailagainstthehandlewhenyoustarttheengineand
usethemachine.Releasethesafetybailtoshutoff
theengine(Figure3).
ThrottleLever
Thethrottlelevercontrolsenginespeed.Withthe
leverdown,intheDISENGAGEposition,theengine
runsatidle.Thisisalsothestartingposition.When
theenginespeedincreases,totheENGAGEDposition,
thecentrifugalclutchengagesandthecuttingwheel
rotates.
g014499
Figure4
1.Throttle—Disengage
position
2.Throttle—Engaged
position
ParkingBrake
Theparkingbrakeholdstheleftwheelfromturningto
securethemachineandforeasymovementofthe
machinefromsidetosidewhengrindingastump
(Figure5).
g241736
Figure5
1.Parkingbrake(engaged)
2.Parkingbrake
(disengaged)
HourMeter
Whentheengineisoff,thehourmeterdisplaysthe
numberofhoursofoperationthathavebeenlogged
onthemachine.
FuelValve
Thefuelvalve(Figure6)islocatedunderneaththe
chokelever.Movetheleverforthefuelvalvetothe
ONpositionbeforeattemptingtostarttheengine.
7

Toro SGR-13 Specifications

General

Cutting Height	Adjustable
Number of Teeth	12
Grind Speed	3600 RPM
Fuel Type	Gasoline
Engine	Honda
