g015174
Figure6
1.Choke
3.Recoil-starthandle
2.Fuelvalve
ChokeLever
Usethechokelever(Figure6)tostartacoldengine.
Beforepullingtherecoil-starthandle,movethechoke
levertotheCLOSEDposition.Oncetheengineis
running,movethechokelevertotheOPENposition.
Donotusethechokeiftheengineisalreadywarmed
uporiftheairtemperatureishigh.
Recoil-StartHandle
Tostarttheengine,pulltherecoil-starthandle(Figure
6)quicklytoturntheengineover.RefertoStartingthe
Engine(page10)forthecorrectstartingprocedure.
Specications
Note:Specicationsanddesignaresubjectto
changewithoutnotice.
CuttingDepth30cm(12inches)
Length
193cm(76inches)
Width
75cm(29.5inches)
Height
107cm(42inches)
Weight
109kg(240lb)
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
Important:Beforeoperating,checkthefueland
oillevel,andremovedebrisfromthemachine.
Also,ensurethattheareaisclearofpeopleand
debris.Youshouldalsoknowandhavemarked
thelocationsofallutilitylines.
BeforeyouStart
•Digawaytheearthandremoveanystonesnear
thetreestumpthatmayinterferewithyourwork.
Checkthatthegroundisfreeofforeignobjects,
suchaselectricalcables,barbedwire,etc.
•Cutortrimthestumpusingapowersaw.
•Reviewallthesafetydecalsonthemachine.
•Ensurethatyouarefamiliarwithsafetyregulations
andshutdownproceduresdescribedinthis
manual.
•Ensurethatallguardsareinplaceandingood
condition.
•Ensurethatthebladesandcuttersareinplace
andingoodcondition.
•Ensurethattheworkarea,cutter,andstumpin
particulararefreefrommetallicobjectssuchas
wire,nails,etc.thatcouldbethrownoutandinjure
personsinthevicinityanddamagetheequipment.
ThinkSafetyFirst
Carefullyreadallsafetyinstructionsandsymbolsin
thesafetysection.Knowingthisinformationcould
helpyouorbystandersavoidinjury.
CAUTION
Thismachineproducessoundlevelsthatcan
causehearinglossthroughextendedperiods
ofexposure.
Wearhearingprotectionwhenoperatingthis
machine.
g229846
Figure7
1.Wearhearingprotection.
