Adjusting the Transmission
Cable
Service Interval: After the first 2 hours
Yearly
If the wheels easily stall out, or if the wheels drive without
engaging the self-propel handle, adjust the transmission
cable.
1
. Loosen the nut on the upper cable clamp, but do not
remove it (Figure 10).
Figure 10
1. Nut
2. Cable
2. Pull the cable down to remove most of the slack in
the cable (Figure 10).
Important: Do not remove all the slack from the
cable. Removing all the slack from the cable may
cause the wheels to engage without engaging the
self-propel handle.
3. Tighten the nut (Figure 10).
Checking the Tire Pressure
Service Interval: Yearly
Set the tire pressure equally in both tires to between 103
and 137 kPa (15 and 20 psi).
16
