Toro® - SnowMaster® Service Manual 3-15
Chassis
3
Table of Contents
CHASSIS
3. Slide the pulley back on the shaft.
4. Using a puller, pull the bearing off the shaft. Remove
the pulley.
Pulley Removal
Removal
1. Remove the transmission from the unit. Remove the
two pulley screws.
2. Using a punch, tap the pin out of the pulley.
Figure 41
Figure 42
Figure 43
Figure 44
