Toro® - SnowMaster® Service Manual
3-14 Table of Contents
CHASSIS
Transmission Removal (Cont.)
Removal (Cont.)
8. Remove the bolts that secure the drive shaft
bearings and retainers to the housing (Figure 39).
9. Slide the transmission to the right until the left hand
axle clears the housing. Lift the transmission up
and out. Disconnect the traction cable (Figure 40).
Figure 39
Figure 40
