Toro STX-38 - Page 36

g004191
Figure55
1.Tractioncontrol
2.Stem,bolt,andnut
5.Adjustthetractioncontrolsothatitrestsush
againstthereferencebarwhenitispulled
straightback(Figure55andFigure56).
g004192
Figure56
6.Tightentheangenutandboltinthetraction
controlstem.
7.Starttheengine.
8.Drivethemachineinreversewiththetraction
controltighttothereferencebar.Ifthemachine
doesnotbackupstraight,completethefollowing
procedure:
A.Shutofftheengine
B.Liftandsupportthemachinesothatboth
tracksareoffthegroundandarefreetorun.
C.Loosentheangenutandboltinthestem
ofthetractioncontrol(Figure55).
D.Loosenthejamnutsonthetractionrods,
underthecontrolpanel(Figure57).
g011476
Figure57
1.Tractionrod2.Jamnut
E.Startthemachineandsetthethrottleto
aboutthe1/3openposition.
WARNING
Whenthemachineisrunning,you
couldbecaughtandinjuredin
movingpartsorburnedonhot
surfaces.
Stayawayfrompinchpoints,moving
parts,andhotsurfaceswhen
adjustingtherunningmachine.
F.Haveahelperholdthetractioncontroltight
tothereferencebarinreverse.
G.Adjustthelengthofthetractionrodsuntil
bothtracksarerunningatthesamespeed.
Note:Youcanalsoadjustthemaximum
reversespeedofthetracksatthistime.
H.Tightenthejamnuts.
I.Adjustthetractioncontrolsothatitrests
ushagainstthereferencebarwhenitis
pulledstraightback(Figure55andFigure
56).
J.Tightentheangenutandboltinthe
tractioncontrolstem.
K.Shutofftheengineandlowerthemachine
totheground.
L.Drivethemachineinfullreverse,checking
toseeifthemachinetracksstraight.Ifit
doesnot,notethedirectionthemachine
veers.Repeattheadjustmentsothatthe
machinetracksstraightinreverse.
36
