Toro Super Bagger - Adjusting the Upper Handle; Adjusting the Cutting Height

AdjustingtheUpperHandle
Height
Youmayraiseorlowertheupperhandletoaposition
comfortableforyou.
Note:Youcannotraisetheupperhandlehigherthan
theangleofthelowerhandle.
1.Loosentheupper-handleknob(Figure17).
g010334
Figure17
2.Movetheupperhandletothedesiredposition
(Figure18).
g010265
Figure18
3.Tightentheupperhandleknobastightasyou
can(Figure19).
g010352
Figure19
AdjustingtheCutting
Height
Adjustthecuttingheightasdesired.Setallthe
cutting-heightleverstothesameheight.Toraiseand
lowerthemachine,refertoFigure20.
g010264
Figure20
1.Raisethemachine
2.Lowerthemachine
Important:Thecuttingheightsettingsare25mm
(1inch);38mm(1-1/2inch);51mm(2inches);64
mm(2-1/2inches);83mm(3-1/4inches);95mm
(3-3/4inches);108mm(4-1/4inches).
