Toro Super Bagger - Installing the Mulch Plug or the Grass Bag; Assembling the Grass Bag

4
InstallingtheMulchPlugor
theGrassBag
NoPartsRequired
Procedure
Youmustcorrectlyinstalleitherthemulchplug(for
recyclingorside-dischargingthegrassclippings)or
thegrassbag;otherwise,theenginewillnotstart.
Themachinehasasafetyswitch(locatedatthe
bottomofthechannelontheupperrightrearofthe
machine)thatpreventsthemachinefromoperating
withoutamulchplugoragrassbaginplace.This
preventsthemachinefromthrowingdebrisatyou
throughtherearopening.
Fortheswitchtodetectthemulchplug,thetopofthe
mulchpluglevermustliefullyinthebottomofthe
channel(Figure7).
g005324
Figure7
1.Thetopofmulchplugleverintheswitchchannel
1.Insertthemulchplugintothemachineifitisnot
alreadyinstalled(Figure8).
g005308
Figure8
2.Squeezethebuttonontheleverwithyour
thumb,andfullyinsertthemulchplugintothe
opening(Figure9).
g005309
Figure9
3.Releasethebuttonontheleverandensurethat
thetopoftheleverliesfullyintheswitchchannel
(Figure10).Ifthetopoftheleverisnotinthe
switchchannel,yourmachinewillnotstart!
6
