Operating the Throttle
Y ou can move the throttle control between the F AST
and S LOW positions ( Figure 21 ).
Always use the F AST position when engaging the PT O.
g295539
Figure 21
Operating the Choke
Use the choke to start a cold engine.
1. Pull up the choke knob to engage the choke
before using the key switch ( Figure 22 ).
Note: Ensure that you fully engage the choke.
Y ou may need to hold the knob up when you
use the key switch.
2. Push down the choke to disengage the choke
after the engine has started ( Figure 22 ).
g295540
Figure 22
1. O N position 2. O FF position
Starting the Engine
Note: A warm or hot engine may not require choking.
Important: Do not engage the starter for more
than 5 seconds at a time. Engaging the starter
motor for more than 5 seconds can damage the
starter motor . If the engine fails to start, wait 10
seconds before operating the engine starter again.
g295541
Figure 23
21
