Pre-Maintenance
Procedures
Releasing the Mower-Deck
Curtain
Loosen the 2 bottom bolts of the curtain to access the
top of the mower deck ( Figure 35 ).
g295619
Figure 35
1. Bottom bolt
2. Curtain
Note: Always tighten the bolts to connect the curtain
after maintenance.
Raising the Machine
Use jackstands to support the machine when you
raise it.
W ARNING
Supporting the machine on the lower mufer
shield ( Figure 36 ) may damage the shield and
cause the machine to fall, injuring you or
bystanders.
Do not use the lower mufer shield to lift or
support the machine.
g299647
Figure 36
1. Lower muf er shield
32
