DriveSystem
Maintenance
CheckingtheTirePressure
ServiceInterval:Every25hours—Checktire
pressure.
Maintaintheairpressureinthefrontandreartiresas
specied.Uneventirepressurecancauseanuneven
cut.Checkthepressureatthevalvestem(Figure42).
Checkthetireswhentheyarecoldtogetthemost
accuratepressurereading.
Refertothemaximumpressuresuggestedbythetire
manufactureronthesidewallofthecasterwheeltires.
Inatethereardrive-wheeltiresto90kPa(13psi).
g000554
Figure42
1.Valvestem
ReleasingtheElectric
Brake
Theelectricbrakereleasesbymanuallyrotating
thelinkarmsforward.Oncetheelectricbrakeis
energized,thebrakeresets.
g027911
Figure43
1.Brakelinkarmontheelectric-brake-controlmodule
2.Left,reartire
1.TurntheignitionkeytotheOFFpositionor
disconnectthebattery.
2.Locatetheshaftontheelectricbrakewherethe
brake-linkarmsareconnected(Figure43).
3.Rotatetheshaftforwardtoreleasethebrake.
