Toro TimeCutter Z4220 User Manual

G005071
2
1
2
3
4
6
5
Figure33
1.Fuellinefromtank
4.Fuellinetoengine
2.Hoseclamp5.Flowdirectionarrow
3.Filter6.Fueltank
4.Squeezetheendsofthehoseclampstogetherand
slidethemawayfromthelter(Figure33).
5.Removethelterfromthefuellines.
6.Installanewlterwiththeowdirectionarrow
comingfromthefueltankandpointingtothe
engine.Movethehoseclampsclosetothelter
(Figure33)tosecureitinplace.
ElectricalSystem
Maintenance
Warning
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandleadcompounds,
chemicalsknowntotheStateofCalifornia
tocausecancerandreproductiveharm.
Washhandsafterhandling.
ChargingtheBattery
RemovingtheBattery
Batteryterminalsormetaltoolscouldshort
againstmetalmachinecomponentscausing
sparks.Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Whenremovingorinstallingthebattery,do
notallowthebatteryterminalstotouchany
metalpartsofthemachine.
•Donotallowmetaltoolstoshortbetween
thebatteryterminalsandmetalpartsofthe
machine.
1.Parkthemachineonalevelsurfaceanddisengage
thebladecontrolswitch.
2.Movethemotioncontrolleversoutwardtothe
parkposition,stoptheengine,removethekey,and
waitforallmovingpartstostopbeforeleavingthe
operatingposition.
3.Removetheleftsideconsoletoaccessthebattery.
RefertheAccessingtheBatteryprocedureinthe
PremaintenanceProceduresforinstructions.
4.Disconnectthenegative(black)groundcablefrom
thebatterypost(Figure34).Retainallfasteners.
31
