Toro TimeCutter Z5035

G005183
1
2
2
1
2
2
3
4
5
6
Figure12
1.Controlpanel4.Continuousvariable
setting
2.Throttle
5.Slow
3.Fast
6.Chokecontrol
4.TurntheignitionkeytoStarttoenergizethestarter.
Whentheenginestarts,releasethekey(Figure13).
Important:Donotengagethestarterformore
than10secondsatatime.Iftheenginefails
tostart,allowa60secondcool-downperiod
betweenattempts.Failuretofollowthese
instructionscandamagethestartermotor.
G005184
1
2
3
4
5
6
1
2
3
4
5
6
7
Figure13
1.Controlpanel
5.Run
2.Ignitionkey—runposition
6.Start
3.Ignitionkey—startposition
7.Chokecontrol
4.Off
5.Aftertheenginestarts,pushdownontheChoke
control(Figure13).Iftheenginestallsorhesitates,
pullupontheChokecontrolandlettheenginerun
forafewseconds.ThenpushdownontheChoke
control.Repeatthisasrequired.
OperatingtheBlades
Thebladecontrolswitch,representedbyapower
take-off(PTO)symbol,engagesanddisengagespower
tothemowerblades.Thisswitchcontrolspowertoany
attachmentsthatdrawpowerfromtheengine,including
themowerdeckandcuttingblades.
EngagingtheBlades
Important:Donotengagethebladeswhen
parkedintallgrass.Beltorclutchdamagecan
occur.
1.Releasepressureonthemotioncontrolleversand
placethemachineinneutral.
2.MovethethrottletotheFastposition.
Note:Alwaysengagethebladeswiththethrottle
intheFastposition.
3.Pulluponthebladecontrolswitchtomoveitto
theOnpositionandengagetheblades(Figure14).
