InstallingtheBlowerBelt
andPoweredBaggerCover
Partsneededforthisprocedure:
1Poweredbaggercover
1Blowerbelt
Procedure
1.Installthebeltaroundtheblowerpulley(Figure
15andFigure16);referto6InstallingtheBlower
Assembly(page13).
g201516
Figure15
BlowerBeltRouting
1.Idler/tensionpulley
3.Blowerbelt
2.Blowerpulley4.Drivepulley
g201513
Figure16
1.Blowerpulley5.Idlerarm
2.Blowerinposition(housing
portionremovedfor
illustrativepurposes)
6.Drivepulley
3.Spring7.Idler/tensionpulley
4.Idler-pulleypost8.Blowerbelt
2.Ensurethatthebeltremainsalignedtothe
blowerpulleywhileyouareinstallingtheblower
assembly.
3.Pullthespringloadedidlerpulleyawayfromthe
xedspringpost,androutethebeltaroundthe
mowerdeckpulley(Figure16).
Note:Ensurethatthebeltisroutedaroundthe
blowerpulleycorrectly.
4.Routethebeltaroundthedrivepulleyas
illustratedinFigure15andFigure16.
5.Installthepoweredbaggercoveroverthebelt
cover,andsecureitbytighteningtheknob
(Figure17).
