InstallingthePulley

Assembly,BeltCover,

andShoulderBolt

Partsneededforthisprocedure:

1Pulleyassembly

1Beltcover

Procedure

1.Removethenutandwasherfromtheright

mowerdeckpulley.

2.Installthepulleyassemblytotherightmower

deckpulleywiththepreviouslyremovednutand

washer(Figure11).

3.Torquethenutto136to149N∙m(100to110

ft-lb).

g337356

Figure11

1.Existingpulleynut

4.Existingdeck(spindle)

pulley

2.Existingwasher

5.Spindle

3.Blowerpulley

4.Installthenewbeltcoveroverthepulley

assemblyusingthe4previouslyremoved

screws(1/4x1/2inch)asshowninFigure12.

g337355

Figure12

1.Beltcover

2.Screw(1/4x1/2inch)
