2.Removetheexistingboltandnutfromthe
mowerdeck(Figure9).
g337317
Figure9
1.Existingbolt2.Existingnut
3.Installtheleftsideofthebafeusingacarriage
bolt(5/16x3/4inch)andangenut(5/16inch)
asshowninFigure10.
4.Loosenthe2carriagebolts(5/16x3/4inch)in
thebafeslots,andslidethebafeuntilthehole
alignswiththeholeinthemowerdeck(Figure
10).
5.InstallbafeasshowninFigure10.
6.Tightenthe2carriagebolts(5/16x3/4inch)in
thebafeslots(Figure10).
g337315
Figure10
1.Innerbafe
5.Installthiscarriagebolt
(5/16x3/4inch)and
angenut(5/16inch)after
slidingthebafe.
2.Holeformowerdeck
installation.
6.Slotsinthebafe
3.Rightblade7.Loosenthese2carriage
bolts(5/16x3/4inch)and
2angenut(5/16inch).
4.Outerbafe
8.Installthiscarriagebolt
(5/16x3/4inch)and
angenut(5/16inch)rst.
11

Toro TITAN Max Specifications

General

Transmission	Hydrostatic
Cutting Width	60 inches
Deck Material	Steel
Engine	Toro
Engine Type	Toro V-Twin
