Page #7 background imageLoading...
Page #7 background image
ProcedureDescription
Qty.
Use
Uppertube1
Screw(1/4x3/4inches)
2
Washer(1/4inch)
2
Locknut(1/4inch)
2
17
Lowertube1
Installthedischargetubes.
18
Nopartsrequired
–
Adjusttheparkingbrake.
19
Nopartsrequired
–
Checkthetirepressure.
Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
1
PreparingtheMachine
NoPartsRequired
Procedure
1.Parkthemachineonalevelsurface.
2.Movethemotion-controlleverstotheNEUTRAL-LOCKposition.
3.Engagetheparkingbrake.
4.Shutofftheengineandremovethekey.
g037289
Figure3
7
