Toro TransPro 200 - Loading the Trailer

SecuringtheTrailertothe
TowVehicle
1.Liftupthetonguehandle(Figure26).
Note:Liftingthehandleretractstheslide
assembly.
g337017
Figure26
1.Tonguehandle
3.Slideassembly
2.Tonguepin
2.Alignthetonguepinwiththetow-vehiclehitch
(Figure27).
g338301
Figure27
1.Tonguepin2.Tow-vehiclehitch
3.Releasethetonguehandle(Figure27)tosecure
thetrailertothetow-vehiclehitch.
Ensurethattheslideassemblyiscentered
belowthetonguepin.
LoadingtheTrailer
PreparingtheLoadtheTrailer
1.Chockthetrailerwheels.
2.Pullthelatchpinsonbothsidesofthetrailerto
releasetherailsorrampsandlowerthemtothe
ground(Figure28).
g338736
Figure28
RailKitequipped
1.Latchpin(rightsideshown)
3.Removethegrassbasketsfromthegreens
mower.
Note:Youcanstorethegrassbasketsinthe
towvehicle.
4.Refertotheappropriateinstructionforan
equippedramporrailkitasfollows:
•RailKit:Installtherailwheelsontothehex
shafts(Figure29).
Note:Therail-wheelclipslotsarefacing
outwardsforallwalk-behindGreensmaster
machines.
12
